Model type

Front loader

Operation voltage

220-240V /50Hz

Rated Frequency

50Hz

Wash Capacity (kg)

10

Spin Capacity(kg)

10

Dryer Capacity(kg)

6

Wash power (W)

250

Spin power (W)

500

Max heating power (W)

2000

Energy Efficiency Class

A+++

Washing Efficiency Index

1.03

Energy Consumption (kWh/Cycle)

0.694

Water Consumption (L/cycle)

68

Variable Spin speed

No spin/400/800/1200/1400rpm

water Temperature(℃)

Cold/30/40/60/96℃

Waterproof Class

IPX4

Noise level  -Wash (PWL)

60 dBA

Noise level  -Spin (PWL)

68dBA

Noise level  -Dry (PWL)

/

Water pressure (MPa)

0.03-0.85mpa

Description

Color

Dim grey

Body material

Steel with powder painting

Inner Drum

Stainless  Steel

Top cover

ABS

Displayer

LED

Key Type

Touch

Door Openning Angle(o)

130o

Door lock

Mechanical

Drain water

Up drain

Door frame

Injection

Door view diameter Φ(mm)

445

Door size( door frame diameter)Φ (mm)

465

Drum shape

Honeycomb

Drum diameteΦ(mm)

φ505*375

Drum Volume(L)

68.5L

Motor type

BLDC Motor(Inverter)

control board

Fully touch screen

Programs

17

Intelligent

Mix

Fiber

Down

Cotton

Intensive

Child

Heavy

Wool

Quick 30'

Quick 15'

60℃ Wash

96℃ Wash

Tub clean

Add wash 30mins

Add wash 20mins

Add wash 10mins

Key buttons

Power on/off

Start/ Pause

Preset

Add Rinse

Spin Speed (rpm)

Temp

Add Wash

Performance

Overheating Control

Yes

Overflow Control

Yes

Auto Balance System

Yes

Memory Of Power Interrupt

Yes

Anti Foam Control

Yes

Fault Check Display

Yes

Time Delay

3-24 hrs

Progress Indicator

Yes

Remaining Time Display

Yes

Child Lock  Display

Yes

Door Lock Display

Yes

Auto Restart

Yes

Hot & Cold Water option

Yes

Half load+

Yes

Anti Wingkle

Yes

3D  Steam wash

No

Deimention

Net Weight (kg)

64

Gross Weight (kg)

70

Product dimention

598*608*845

Package dimention

Loading Qty (40HQ)

Stacking layers
