Model type

Front loader

Operation voltage

220-240V /50Hz

Rated Frequency

50Hz

Wash Capacity (kg)

8

Spin Capacity(kg)

8

Dryer Capacity(kg)

4

Wash power (W)

250

Spin power (W)

500

Max heating power (W)

1800

Energy Efficiency Class

A+++

Washing Efficiency Index

1.03

Energy Consumption (kWh/Cycle)

0.986

Water Consumption (L/cycle)

68

Variable Spin speed

No spin/400/800/1200rpm

water Temperature(℃)

Cold/30/40/60/96℃

Waterproof Class

IPX4

Noise level  -Wash (PWL)

60 dBA

Noise level  -Spin (PWL)

72dBA

Noise level  -Dry (PWL)

/

Water pressure (MPa)

0.03-0.85mpa

Description

Color

White

Body material

Steel with powder painting

Inner Drum

Stainless  Steel

Top cover

ABS

Displayer

LED

Key Type

Touch panel

Door Openning Angle(o)

130o

Door lock

Mechanical

Drain water

Up drain

Door frame

Injection + oil painting

Door view diameter Φ(mm)

445

Door size( door frame diameter)Φ (mm)

465

Drum shape

Honeycomb

Drum diameteΦ(mm)

φ505*325

Drum Volume(L)

58.5L

Motor type

BLDC Motor(Inverter)

control board

1 knob + 7 touch keys

Programs

16

Normal

15' super wash

30' quick wash

underwear

shirt

Kids wear

Spin only

Rinse+Spin

96℃ Drum cleaning

Intensive

cotton

Down Jacket

Gentle

Wool

Silent wash (Night wash)

96℃  antibacterial 96

/

Key buttons

Power on/off

Starr/ Pause

Preset

Add Rinse

Spin Speed (rpm)

Temp

Performance

Overheating Control

Yes

Overflow Control

Yes

Auto Balance System

Yes

Memory Of Power Interrupt

Yes

Anti Foam Control

Yes

Fault Check Display

Yes

Time Delay

3-24 hrs

Progress Indicator

Yes

Remaining Time Display

Yes

Child Lock  Display

Yes

Door Lock Display

Yes

Auto Restart

Yes

Hot & Cold Water option

Yes

Half load+

Yes

Anti Wingkle

Yes

3D  Steam wash

Yes

Deimention

Net Weight (kg)

62

Gross Weight (kg)

68

Product dimention

598*608*845

Package dimention

670*700*930

Loading Qty (40HQ)

153

Stacking layers

4
